SIEG C6/ 250x550mm Bench Lathe
SIEG C6/ 250x550mm Bench Lathe

SIEG C6/ 250x550mm Bench Lathe

SKU: 080-010-60000
Sale price
$2,142.25
Regular price
$2,255.00
You save
$112.75 (5%)
Option:
C6 Machine Only
In stock and ready for shipping

Product Informations:

Features:

Leadscrew Guard
Cuts Metric & Imperial Threads
Emergency Stop Button
Switched Chuck Guard
Heavy Duty Cast Iron Bed
Metal Gears

Specifications:
Swing Over Bed: 250mm
Distance Between Centres: 550mm
Spindle Bore: 20mm
Spindle Taper: MT3
Tailstock Taper: MT2
Cross Slide Travel: 110mm
Compound Travel: 75mm
Range of Threads: 0.4 - 3mm ( 12 Thread Pitches )
10-44 TPI ( 8 Thread Pitches )
Spindle Speed: 125 - 2000rpm ( 6 step )
Power Rating: 1000W
Output: 550W
Overall Dimension: 1170x640x580mm
Weight (Net/Gross): 165 / 180kg

Standard Accessories:
125mm 3-Jaw Self-Centering Chuck
MT2 Dead Centre
MT3 Spindle Centre
Fix Steady & Travelling Steady
Face Plate
Change Gear Set
Wrench Set


Starter Kit Includes (Optional):

  • TiN Carbide Indexable Turning Tools 7pcs Set
  • Quick Change Tool Post with 3 Tool Holders ( Tool post with 3xRegular holders)
  • 8mm Parting Off Tool
  • Keyless Drill Chuck, JT3, 1-16mm
  • MT2/JT3 Drill Chuck Arbor
  • HSS Drill Bit 1-6mm 51pcs Set, 0.1mm inc. Split Head from 3mm up
  • HSS Drill Bit 6-10mm 41pcs Set, 0.1mm Inc. Split Head
  • HSS Centre Drill Set 4pcs Set 1.6-4mm
  • MT2 Revolving Centre

1 Year Extended Warranty Now Available! Click to learn more.

          SIEG Lathe Comparison
    Specs. C0 C2 C3&C3P SC3/SC20 SC4 C6 SC6 SC10
    Swing Over Bed 110mm 180mm 210mm 250mm 305mm
    Distance Between
    Centres    		 125mm 300mm 350mm 400mm 510mm 550mm 700mm
    Spindle Bore 10mm 20mm 38mm
    Spindle Taper - MT3 MT5
    Tailstock Taper - MT2 MT3
    Cross Slide Travel 50mm 65mm 100mm 110mm 155mm
    Compound Travel - 55mm 70mm 75mm 80mm
    Tool Size (Height) 8mm 10mm 12mm 16mm
    Power Rating 210W 400W 550W 650W
    Brushless     		1250W
    Brushless     		1000W 1250W
    Brushless     		1810W
    Brushless
    Output 150W 250W 350W 500W 1000W 550W 1000W 1500W
    Range of Thread
    (Metric)    		 - 0.4-2.0mm
    (10 Pitches)    		 0.25-3.0mm
    (17 Pitches)    		 0.4-3.0mm
    (12 Pitches)    		 0.25-2.5mm
    (14 Pitches)
    Range of Thread
    (Imperial)    		 - - - - 8-24TPI
    (10 Pitches)    		 10-44TPI
    (8 Pitches)    		 12-96TPI
    (9 Pitches)
    Weight 14kg 40kg 44kg 50kg 135kg 145kg 215kg
